盾構機前盾翻身吊裝靜力學分析與研究

打開文本圖片集

摘 要：以盾構機前盾為研究對象，對其翻身吊裝進行受力分析和研究，推導出各個吊繩的受力函數和變化規律，并得出各個吊耳的受力函數。利用ANSYS Workbench軟件對各個吊耳施加載荷函數，進行有限元靜力學仿真分析，驗證了各個吊耳的強度和剛度滿足使用要求，為盾體等大型設備的翻身吊裝提供參考計算方法。

關鍵詞：前盾；翻身吊裝；吊繩；吊耳；靜力學分析

中圖分類號：TB121  文獻標志碼：B  文章編號：1671-5276（2025）01-0095-09

Static Analysis and Research on Turnover Lifting of Front Shield of Shield Machine

Abstract：Taking the front shield of shield machine as the research object， analyzes and studies its turnover hoisting stress， deduces the stress function and change law of each lifting rope and obtains the force function of each lifting lug. The load function of each lifting lug is applied by using the ANSYS Workbench software， and the finite element static simulation analysis is carried out， which verifies that the strength and stiffness of each lifting lug meet the use requirements and provides a reference calculation method for the turnover hoisting of large equipment such as shield.

Keywords：front shield; turnover lifting; lifting rope; lifting lug; static analysis

0 引言

隨著國家隧道建設行業的快速發展，盾構機因具有人力投入少、施工速度快和安全性高等特點，被廣泛應用在鐵路、公路、地鐵和水利等隧道建設等工程領域［1］。（剩余7639字）
