高速數控車床電主軸過盈配合仿真分析及性能評估

打開文本圖片集

中圖分類號：TH122 文獻標志碼：A 文章編號：1671-5276（2025）03-0139-06

Interference Fit Simulation Analysis and Performance Evaluation of High Speed CNC Lathe Spindle

WANG Jianjun1a，1b，WANG Yingla，1b，WANG Shuai2，YANG Hongjun3，MU Longtaola，1b， ZHANG Xiaoye4 （1.a.Collgeof Mechanical Engineering；b.Xianyang High-End CNC Machine TolKey Components Engineeing Technology Research Center， Shaanxi Polytechnic Institute，Xianyang 712Oo0， China; 2. Xi'an Jingdiao Precision Machinery Engineering Co.，Ltd.，Xi'an，71O061， China; 3. Baoji Machine Tool Group Co.，Ltd.，Baoji 721013，China； 4.Aerospace Propulsion Technology Research Institute，Xi'an 71O1Oo，China）

Abstract：Researchontheinterferencefitofahigh-speedCNClatheelectricspindlerotorwasconductedtobreedideasforits simulationdesign.Thecoldshrinkfitfunctionoftheanalysissoftwarewasapliedtosolvethereductionindiameteroftherotor sleeveafter thermal expansionasembly，andtheeffectsof temperatureriseandcentrifugal forceoncontactpressure were analyzed.Therotationalspeed，transmited torquevalue，andsafetyfactorwereobtainedundertwoworking modes，andthe interference fit performance was evaluated.

Keywords：electric spindle； interference fit；cold shrink fit；contact pressure；transmitted torqut

0 引言

過盈配合能夠傳遞較大轉矩，承受變載荷和振動，且轉動平衡易于控制，因此是高速機床行業中電主軸轉子與主軸連接的理想方式。（剩余7268字）
