基于PSO算法的IMC-PID加熱爐溫度控制研究

打開文本圖片集

中圖分類號：TP273 文獻標志碼：A 文章編號：1671-5276（2025）03-0038-05

Research on IMC-PID Heating Furnace Temperature Control Based on PSO Algorithm

ZHOU Tong'，ZHU Qian2，ZHANG Kuikui3， ZHOU Tong3，WANG Cunsong3，BO Cuimei1 （1. College of Electrical Engineering and Control Science，Nanjing Tech University，Nanjing 211816， China; 2.Jiangsu Academy of Chemical Inherent Safety，Nanjing 210o09，China； 3.Institute of Intelligent Manufacturing，Nanjing Tech University，Nanjing 21ooo9，China）

Abstract：Thetemperatureof theheatingfurnacehascharacteristicsof nonlinearityandlarge hysteresis，withmanydisturbance factors，andtraditionalPIDcontrolersandtheirparametertuningmethodssuferinsuficiencesinmeetingtherequirementsof rapidheating andnonovershoot processcontrol.Thisarticle proposes anIMC-PIDcascadecontrolmethodbasedontheParticle SwarmOptimization（PSO）algorithm.Interalmodelcontroltheoryisaplidtoimprovethemaincontroller，andPSOalgorithm isusedtooptimizeandtune thecontrolerparameters toupgradethetracking performanceandanti-interferenceperformanceof thecontrolsystem.Numericalsimulationsareconductedtoverifytheefectivenessofthedesignedcontrolsystemincotroling the temperature of the heating furnaceunder model matching and mismatch conditions （parameters k ， T ， τ Effectiveness and feasibility under uniform perturbation of 20% ）with fast response and low overshoot characteristics.

Keywords： heating furnace；temperature control； cascade control system；internal model control；PSO algorithm

0 引言

加熱爐作為石油化工生產過程的核心設備[1]，在工藝介質的升溫和氣化過程起到關鍵作用，其中加熱爐的溫度控制精度直接影響生產安全、反應效率和產品質量。（剩余5485字）
