彈性連接器盲配安裝分析及結構設計

打開文本圖片集

中圖分類號：TH131 文獻標志碼：B 文章編號：1671-5276（2025）03-0066-05

Blind Installation Analysis and Structural Design of Elastic Connector

YANG Tingting

（The38thResearch institute ofCETC，Hefei 230011，China）

Abstract：Elasticconnector，anewtypeofconnectorwithadvantagessuchassmallsize，highintegration，isoneofthemost importantconnectionmethodsforfuturehighintegrationstructuraldesign.Initstightstructuraldesign，theconnectorrequires onlyasmalleightspaceforsignal transmision，ut great strictnessforblindmathingstructuretolerancecontrol.Inorderto designbetterblindstructureof elasticconnector，anewstructure tolerancecalculationmethodisproposed.Thetheoretical formulaofelasticpindeviationrelationisestablished，andtherelationbetweenelasticpindeviationandstructuraldimension tolerance isanalyzed.Thetheoreticalmodelofblindstructuredesignof elasticconnectorisfurtherestablished，basedonwhich thedimensionaltoleranceofthestructureisderivedinactualsituation.Theproposedmethodprovidesatheoreticalbasis foreven moreimportant blind configuration design of elastic connectors in the future.

Keywords：elasticconnecor；toleranceanalysis；blindconnectorinstallation；structuraldesign；theoretical analysis

0 引言

隨著電子信息相關學科技術的不斷發展，對現代軍用、民用電子裝備性能的要求也大幅提高。（剩余4763字）
