一種輪式裝載機舉升機構同步控制系統的優化設計

打開文本圖片集

中圖分類號：TH243 文獻標志碼：A 文章編號：1671-5276（2025）03-0090-06

Optimization Design of a Synchronous Control System for Lifting Mechanism of Wheel Loader

YAODan，ZHENGKai

（Xi'an TrafficEngineeringInstitute，Xi'an71O3OO，China）

Abstract：Regarding thesynchronous position deviationcausedby hydraulic cylinders during the working processof lifting mechanisms forwheelloader，anoptimized synchronouscontrolsystemwas designed.Thebasic structureandcoreparametersof thelifting mechanismforwheelloaderswereelaborated，andamathematical modelofthelfting mechanismwas establishedand mechanical analysis was conducted. Schematic diagram of the hydraulicsystem of the lifting mechanism was drawn using FluidSIMsoftware，andsimulationanalysiswasconducted.Usingsensorsand electromagneticproportional directionalvalvesas hardware cores，a simulation model ofasynchronous control system withPIDcontrol link was constructed byAMESim，and simulationanalysis wasconducted.Theanalysisresultsindicate that the application of PID controlsystem improvesthe synchronizationaccuracyof the lifting mechanismof heavy-dutyvehicles，andmaintains thecontinuousandstableoperationof theliftingmechanism ofwheel loader.

Keywords：wheel loader；liftingmechanism；synchronouscontrol；AMESim

0 引言

工程機械種類繁多且市場占有率較大，是進行生產活動及工程建設與施工的重要機械設備，被廣泛應用于生產建設等領域。（剩余5849字）
