六維力傳感器輸出信號采集系統研究

打開文本圖片集

中圖分類號：TN713-34；TP212 文獻標識碼：A 文章編號：1004-373X（2025）10-0152-05

引用格式：，.六維力傳感器輸出信號采集系統研究[J].現代電子技術，2025，48（10）：152-156.

Abstract：Inordertoachieve stable，high-speed，andacurateacquisitionandonlinedecouplingoftheoutputsignalof the strain typesix-dimensional forcesensor，acollectionsystem thatcanachieveonlinedecouplingof theoutput signalofthesixdimensionalforcesensorisdesigned.Inthesystem，STM32G431C8T6isusedasthemaincontrolchip，andMAX11270isused toconvertthecolectedvoltagesignalintothedigitalsignalandoutputit.Thedigitalsignalistransmitedbacktothemain controlchipymeansofSPcommunicationrocessdbyButterworthigitalfilteranddecoupledolineusingoflietraied decouplingparametersinthemaincontrolchip.Itisoutput totheuppercomputerbymeansof Modbusprotocol.The experimentalresearchwasconductedbymeansofcalibrationsamplesobtainedfrom staticcalibration.Theexperimentalresults show that，afterdecoupling，theerror-Iis not greater than2.5%FS，and theerror-II isnot greater than1.7%FS.

Keywords：six-dimensional forcesensor;signalacquisition;digital filtering;STM32;onlinedecoupling;analog-to-digital conversion

0 引言

六維力傳感器因能夠?qū)Χ嘧杂啥仁芰?shí)現高精度同步測量，已被廣泛應用于機器人和其他先進制造設備等高端生產力領域[1-3]。（剩余5991字）
