SST中輔助電源變壓器的絕緣結構設計

打開文本圖片集

中圖分類號：TM41 文獻標志碼：A 文章編號：2095-2945（2025）19-0048-05

Abstract：Withtheimprovementofvoltagelevels，theinsulationproblemsofauxiliarypowertransformersusedfor independentpowersupplyinSolidStateTransformers（SSTs）havebecomeincreasinglyprominent.Iftheinsulationisnotproperly designed，seriouspartialdischargeswillbecausedresultinginisulationagingfailureandaffectingtheoraloperationof electricalequipment.Tothisend，theauthorhaveproposedatechnicalsolutionusingacombinationofmetalshieldedinsulated wiresandmagneticringsintheband.Itcannotonlyhomogenizetheelectricfielddistributionandincreasethelevelofpartial discharge，butalsoreducethevolumeocupiedbythetransformerandimprovethepowerdensityofthesystem.Bycomparing andanalyzingthecharactersticsoftheproposedauxiliarypowertransformerandtheexisting primaryauxiliarypowertransformer intermsofelectricfielddistributionandvolumeocupation，theproposedschemehasbeeverfiedintermsofoptimizingthe electric field distribution（reducing the maximum electric field value by 65 % ）and reducing the transformer volume（saving the occupied space and volume by about 1/3 ）

Keywords：solidstate transformer，insulationstructure;auxiliarypowersupply；transformer;electricfielddistribution

固態變壓器（Solid State Transformer，SST），亦稱電力電子變壓器（PowerElectronicTransformer，PET），是一種融合電力電子技術與高頻變壓器的新型電力電子設備，兼具電氣隔離、電壓變換及功率調節與控制等多重功能優勢[I-3]。（剩余4390字）
