鋼殼沉管隧道通用件設計方案研究及應用

打開文本圖片集

中圖分類號：U671.2

文獻標志碼：A

Research and Application of Common Parts Design Scheme forSteel-Shell Immersed Tunnels

ZHU Xiaoyan'， LIU Ya1 ，MALing'，LIUDi2，PANJunfal（1CSSCHuangpuWenchongSipBuldingompanyLimited，Guangzou50715，China;2.Shenzen-ZhongshanBridgeanagementCteZhongshan 528403， China）

Abstract： Large-scale steel structures feature high-volume production， structural uniformity， and internal similarity withnumeroussmal-sized，lightweight，andidenticalcomponents.Traditional designand nestingmethods suffer from prolonged design hours，low field kitting efciency，part los，and material underutilization.Focusing on a steel-shellimmersed tunnel project，this studyanalyzes the similarityof numerous smallconnectors within tunnel segments.Acommon parts design scheme is proposed，enhancing nesting effciency，material utilizationof small parts，field kiting efficiency，andassembly productivity，thereby improving enterprise profitability.This approach offers references for shipbuilding and large-scale steel construction.

Key words： common parts; nesting; cost effciency enhancement; immersed tunnel

1 引言

在船舶、鋼殼沉管、橋梁等大型鋼結構的設計建造過程中，通常以模塊為單位開展生產設計、套料加工和裝配建造工作。（剩余3344字）
