基于響應面法的小型井下油水分離器操作參數優化

打開文本圖片集

Cao Yanfeng，Qiu Hao，Wen Min，et al.Operating parameter optimization of small downhole oil-water separato based on the response surface method [J]. China Petroleum Machinery，2O25，53（5）：125-132.

關鍵詞：油水分離器；響應面法；操作參數；結構優化；分離效率；數值模擬中圖分類號：TE925文獻標識碼：A DOI：10.12473/CPM.202405023

Operating Parameter Optimization of Small Downhole Oil-Water Separator Based on the Response Surface Method

Cao Yanfeng' Qiu Hao' Wen Min1 Wang Tong2 Zhao Junwei2Zou Minghua1 Pan Hao （1. CNOOC Research Institute Co.，Ltd.；2.China Oilfield Services Limited）

Abstract：The oil-water separator can effectively separate oil-water mixture，and also improve production efficiency，alleviate environmental pollution，and reduce production costs.To further improve the eficiency of the oil-water separator and reduce the overflow pressure loss， taking a smalldownhole oil-water separator as an example，basedon the response surface method，the mathematical relations between three operating parameters（oil phase density，treatment capacity and diversion ratio）and separation eficiency or pressure drop were established， the separate influence of oil phase density，treatment capacity and diversion ratio on separation eficiencyand pressure drop wasanalyzed，and their interactive relationships were discussed.Finally，the optimal combination of operating parameters was determined，and the response model was verified.The results show thatthe determination coefficient for linear regression R2 is O.972 9 and O. 991 1 respectively in variance analysis and significance test， indicating a good correlation of the response model. When the oil phase density is 800kg/m3 ，the incoming fluid treatment capacity is 1.413m3/h ， and the diversion ratio is 39.419% ，the separation effect is optimal. The separation efficiency increases from 79.56% to 96.37% after optimization of operating parameters. The volume fraction of theoil phase near the undertow of the separatoris obviously reduced after optimization，and that near the overflow （oil phase outlet）is increased by 5 percentage points.The research results and the proposed method provide guidance for the structural optimization and field application of downhole oil-water separators.

Keywords： oil-water separator; response surface method； operating parameter； structural optimization; separation eficiency；numerical simulation

0引言

2023年，中國油氣產量當量超3.9億t，連續7年保持千萬噸級快速增長，年均增幅達到1170萬t，不斷鞭策著采油技術的發展[1]，而促進井下油水分離技術朝高效、穩定、小型化、低成本、智能化的方向發展[2]。（剩余12817字）
