立輪輔助鉆進單元試驗與數值模擬分析

打開文本圖片集

中圖分類號：TE921 文獻標識碼：A DOI：10.12473/CPM.202402062

YangYan，Huang Kuilin，Song Dongdong，et al.Test and numerical simulation analysis of vertical whel assisteddrilling unit[J].China Petroleum Machinery，2025，53（5）：48-55.

Test and Numerical Simulation Analysis of Vertical Wheel Assisted Drilling Unit

Yang Yan1，2.3Huang Kuilin 1，4 Song DongdongHuang Zequan° Qiu Shunzuo 1，2 Hu Jiaqi2 （1.MOEKeyLaboratoryforOilndGasEquipment，SouthwestPetroleum University；2.Facultyof IntenationalApliedTechnoogy，Yibin University；3.YibinEngnering TechnologyResearchCenterforFlexibleProductionLine ManagementandService; 4.SchoolofMechanicalEngineering，SouthuestPetroleumUniversity；5.CCDCChuanxiDrilingCompany；6.FacultyofIntellnt Manufacturing， Yibin University）

Abstract： In difficult-to-drilldeep formations，PDC bits struggle to penetrate and have low rock-breaking efficiency，and provide poor bit azimuth stability in stering driling.This paper presents a PDCbit with a wheel and axle integrated vertical wheel cutting structure.PDC rock-breakingunit was tested under vertical wheel predamage conditions at variable cuting depth to compare the PDC rock-breaking effects under PDC paralel cutting and vertical wheel pre-damage conditions.Moreover，numerical simulation analysis was conducted to reveal the working mechanism of vertical wheel assisted drilling.The research results show thatthe tangential and axial dynamic load factors of vertical wheel assisted PDC rock cutting are 43.31% and 36.63% lower respectively than PDC rock cutting alone.During the rock breaking process，the cutter of the vertical wheel periodically participates in intermittent cutting，and the cuting state undergoes periodic changes，exhibiting obvious“milling”characteristics.The vertical wheel and PDC cutteron the vertical wheel type PDC bit scrape and cut rocks in a nonparallel way，forming a spiral downhole morphology，which helps PDC cuter to invade rocks and improve rock breaking efciency，The vertical whel cutting structure plays a role of sharing pressure and cushioning for PDC cutter，improving the overallstabilityand service life of the bit.The research results contribute toa deep and thorough understanding of the complex motion and working mechanics characteristics of vertical wheel type PDC bit.

Keywords： PDC bit； working mechanism; vertical wheel; milling； share pressure and cushion

0引言

我國大部分未開發的油氣資源埋藏在深層[1-3]，PDC 鉆頭 + 導向鉆井技術廣泛應用于深井、超深井的油氣開發中，可大大提高深井油氣產量，降低綜合成本[4-5]。（剩余11023字）
