基于EMD小波降噪的螺桿泵共振轉速識別方法

打開文本圖片集

中圖分類號：TE933文獻標識碼：ADOI：10.12473/CPM.202404086

Zhao Haiyang，Zhang Yu， Zhang Xiaojuan，et al.A method for identifying resonance speed of progressive cavit pump based on EMD wavelet denoising[J]. China Petroleum Machinery，2025，53（5）：102-109.

A Method for Identifying Resonance Speed of Progressive Cavity Pump Based on EMD Wavelet Denoising

Zhao Haiyang'Zhang Yu'Zhang Xiaojuan2Yuan Yu'Zhang Chenxi1 （1.SchoolofMechnicalScienceandEngnering，NotheastPetroleum University；2.OilProductionTechnologyResearchstit te of No. 4 Oil Production Plant， Daqing Oilfield Limited Company）

Abstract： The resonance phenomenon of sucker rod of progressive cavity pump（PCP）may lead to a decrease in the bearing capacity of the drive unit，a decrease in the sealing between the tubing and the oil pol，and accidents such as eccentric wear and breakage of the sucker rod.It has become the main factor afecting the safe operation of the pump.During the production，resonance can be avoided by controling the working speed of he sucker rod.However，the calculation of theoretical resonance speed maybe deviant due to the actual working conditions.This paper presents a method for identifying the resonance speed of PCP based on vibration signal feature extraction.A resonance speed vibration test of surface direct driving PCP was carried out to build a dataset of vibration signals under variable speed conditions.Then，by introducing the evaluation method-standard score（Zscore），the kurtosis factor was selected as the resonance speed feature identification indicator.On this basis，a vibrationsignal denoising method based on empirical mode decomposition （EMD）wavelet was proposed to achieve effctive extraction of resonance state feature information of PCP，thereby improving the actual resonance speed identification accuracy.The research results provide technical support for the safe and stable operation of PCP.

Keywords： surface direct driving PCP；resonance speed；empirical mode decomposition；soft threshold wavelet denoising； feature extraction

0引言

地面直驅螺桿泵因其結構簡單、效率高及能量損耗低等特點，在全國各大油田得到了廣泛應用。（剩余10866字）
