多維參數譜重構的FDA-MIMO雷達超分辨目標定位方法

打開文本圖片集

中圖分類號：TN957.52 文獻標志碼：A DOI：10.12305/j.issn.1001-506X.2025.05.09

Abstract：Two low-complexity angle-distance super-resolution estimation algorithms are proposed to solve coupling problem of angle and distance in the target localization process of frequency division array multipleinput multiple-output （FDA-MIMO）radar，which are namely the two-dimensional rooting（2D-root） algorithm and thereduced dimensional estimation of signal parameters via rotational invariance techniques （RD-ESPRIT） algorithm.Firstly，anangle-distance two-dimensional spectral reconstruction method is proposed to perform one-dimensional equivalent stripping of the two-dimensional parameter spectrum.Differ from traditional rooting super-resolution algorithms，the 2D-root algorithm utilizes a matrix subspace rooting method to construct dual rooting polynomials for high-precision estimation of anglesand distances，and automatically pairs the parameters.Meanwhile，in order to further reduce the computational complexity of rooting computation，the

RD-ESPRIT algorithm utilizes the linear relationship inherent in the reconstructed angle spectrum to obtain rotational invariance of the signal subspace，thereby achieving eficient solution of the target angle.Computer simulation experimental results show that the two proposed algorithms can improve parameter estimation accuracy while reducing the complexity of traditional search-based target localization algorithms.

Keywords： frequency diverse array multiple-input multiple-output （FDA-MIMO） radar；super resolution; spectrum reconstruction；decoupling

0 引言

自雷達系統的概念提出以來，其主要作用之一就是對空間目標進行精準定位，即利用先進的信號處理方法從雷達回波中提取目標的角度和距離信息[1]。（剩余14065字）
