伴生氣凝液回收與液化工藝聯產技術研究

打開文本圖片集

DOI：10.3969/j.issn.1001-2206.2025.03.011

Research on co-production technology of condensate recovery and liquefaction process of associated gas

LIU Haiying Sulige Exploration and Development Branch of Huabei Petroleum Administration Co.，Ltd.，Ordos O17004， China

Abstract：Insomeoilfields，asociatedgasisusuallydirectlyventedduetodispersed gassources，smallgasvolume，andremote distancefromthegastransmisionnetwork，resulting inresourcewasteandenvironmentalpolution.Torealizetherecoveryand comprehensiveutilizationofasociatedgas，theprocessesofcondensaterecoveryandliquefactionwerecombinedandsharedaseof refrigerationcclestoformacoproductionproessofthegassubcooledprocess（GSP）andsteammethanereforming （SMR）andthe redundantequipmentintheproceeswassimplified.Theinfluenceofchangesintheco-productionprocessparametersonthpecific power consumption， liquefaction rate， and C2+ recovery rate was analyzed.Finally，the differences between the single production process andco-productionprocesswerecompared.Theresultsshowthatthelowertmperatureofthelow-temperatureseparatorindicatesthe the higher tower pressure of the demethanizer，smaller gas-phase split ratio，lower specific power consumption and C2+ recovery of the co-productionprocs，andigerliquefactionrate.Teinfueneoftheixingrefrigerantatioonspecificpowerconsumptiondepnds onthechangeofomponentswithalowerboilingpoint.Byotiizingtemiingrefrigerantatioflowrateandrefrigerantpreuete specific power consumption can be greatly reduced. The specific power consumption， liquefaction rate and C2+ recovery of this process are 0.501 4 kW·h/kg， 91.21% and 85.55% ，respectively. Compared with those of the contrast process，the number of equipment is smaller，and the heat transfer of the cold boxis less required.

Keywords：condensate recovery; liquefaction; GSP; SMR; co-production; specific power consumption

隨著國家“碳中和”“碳達峰”目標的提出，推動傳統能源行業轉型、大力推廣清潔能源成為當前油氣田企業發展的重要方向。（剩余5754字）
