轉子靜偏心對電驅總成NVH的影響

打開文本圖片集

中圖分類號：U469.72；TM303.3；TP391.99 文獻標志碼：B

Influence of rotor static eccentricity on NVH of electric drive assembly

LI Yimin12，WU Hang'，AN Pifu'

（1.Chongqing Tsingshan Industrial Co.，Ltd.，Chongqing 402760，China； 2.Hangzhou Winning Automobile Technology Co.，Ltd.，Hangzhou 3111OO，China）

Abstract： To study the effct of rotor static eccentricity on the NVH performance of an electric drive assembly，an elastic multi-body dynamic model of a certain electric drive assembly is built，and the vibration velocity of the shellsurface is computed，which is in good agreement with the test results.The electromagnetic excitation loads generated by diffrent static eccentricities of the rotor is apply to the dynamic model to evaluate the impact of rotor eccentricity on the dynamics and NVH performance of the electric drive assembly. The results show that the rotor eccentricity not only changes the dynamic performance of the motor itself， but also afects the dynamic behavior and NVH performance of the entire electric drive assembly；with the increase of eccentricity，the load on the rotor bearing and the left end bearing of the input shaft of the reducer deteriorates significantly，and the transmission errr of the gear and the load distribution factor of the tooth surface increase，which means that the meshing state of the gear deteriorates.

Key words： electric drive；elastic multi-body dynamic； static eccentricity； electromagnetic excitation；transmission error； load distribution factor；vibration

0引言

在新能源汽車中，集成電機與齒輪減速器驅動總成應用越來越廣泛。（剩余7645字）
