熱處理試板模擬大型過程設備現場熱處理工藝

打開文本圖片集

中圖分類號：TG156.1 文獻標志碼：A 文章編號：1000-582X（2025）04-054-13

doi：10.11835/j.issn.1000-582X.2025.04.005

引用格式：，等.熱處理試板模擬大型過程設備現場熱處理工藝[J].重慶大學學報，2025，48（4）： 54-66.

Simulation of in situ heat treatment processes for large equipment using a heat treatment test plate

YUAN Shuxia'，LI Jiahao'，LIN Yalan2， ZHANGYaozu2，LI Yinhu' （1. School of Mechanical Engineering， Xi'an Shiyou University， Xi'an 710065， P. R. China； 2. Equipment Manufacturing Branch of Shaanxi Petroleum Chemical Engineering and Construction Co.， Ltd.， Xi' an 712100， P. R. China）

Abstract： To establish a localized heat treatment technique，a heat treatment test plate capable of withstanding destructive testing was developed.Through boundary condition analysis， the equivalent boundary conditions for both the heat treatment test plate and the processequipment were determined.The numerical thermal simulation method，implemented by ANSYS software and validated through experiments，was employed to analyze the heat treatment processforthe test plate and the corresponding equipment.The resultsdemonstrate that the temperature distributionand holding temperatureof the testplate alignclosely with those of the equipment，confirming the feasiblity ofderiving the equipment's heattreatmenttechnique from the test plate results.However， the complex manufacturing processes of the test plate make single-use applications economically unviable.To enhance its utility， thermodynamic and heat transfercalculations were used toformulate equations fortest plates with varying material and thicknesses.These formulasalow for thedetermination of heat treatment techniques for equipment of different materials and thicknesses using a single testplate.Theresults indicate that the temperature gradient across the plate thickness increases with thickness， and when the thickness exceeds 120mm ， single-sided heating may cause treatment failure due to excessive temperature differences between the two sides.Moreover， material properties such as specific heat capacity andthermal conductivity influence the heattreatment process： materials with higher specific heat capacity have lowerthermal conductivity，and higher heat treatment temperatures require longer processing times and greater energy consumption.

Keywords： heat treatment test plate； in situ heat treatment； process equipment； heat treatment process

大型過程設備受限于熱處理能力及運輸能力，無法在廠內完成全部制造工作，需分段制造并熱處理，最終在現場拼焊完成。（剩余11660字）
